PI cua sov caij (polyimide cua sov zaj duab xis / cua sov caij)
Tso lus
Lub PI cua sov lub caij yog ib qho ultra-nyias, hloov tau yooj yim nto cua sov ua los ntawm hlau-etched alloy foil thiab PI (polyimide) insulating zaj duab xis, kub- nias ntawm qhov kub thiab txias. Cov tub ntxhais yog hlau-chromium-aluminium/nickel-chromium tiv thaiv cua sov Circuit Court, nrog ob txheej ntawm cov xim daj PI zaj duab xis ua cov txheej txheem tiv thaiv.
Basic Parameters
⊙ Thickness: 0.13-0.25mm, nyias nyias
⊙ Voltage: DC / AC 1-220V, feem ntau siv qis voltage: 12V, 24V, 36V
⊙ Ntev -lub sijhawm ua haujlwm kub: -40℃-120-150℃; Lub sij hawm luv luv siab tshaj 200-250℃(nyob ntawm cov nplaum txheej)
⊙Ntau qhov hluav taws xob: AC1000-1500V rwb thaiv tsev tiv thaiv hluav taws xob
⊙Power Density: Pom zoo rau cov khoom ua haujlwm nrog cov cua kub zoo: Tsawg dua lossis sib npaug li 1-1.5W / cm²; Pom zoo rau kev tshem tawm cua: Tsawg dua lossis sib npaug ntawm 0.5-0.8W / cm², lub zog ntau dhau tuaj yeem hlawv cov yeeb yaj kiab.
⊙ Yam tsawg kawg Bending Radius: 0.8mm, tuaj yeem rov khoov duav, haum rau qhov nkhaus thiab qhov tsis sib xws.
⊙Resistance kam rau ua: Feem ntau ± 5% 10%, resistors, qhov ntau thiab tsawg, qhib, thiab cov hlau lead ua haujlwm tuaj yeem kho raws li qhov xav tau.
Core Zoo
●Ultra-nyias thiab yoog raws, haum rau qhov chaw nkhaus thiab nqaim qhov khoob, cov nplaum ncaj qha- thim rov qab installation.
● Deg etching cua sov, tsis sib xws kub, cua sov ceev, tsis muaj qhov chaw kub kub, tswj qhov kub thiab txias.
●High rwb thaiv tsev zog, roj-resistant, hnyav-resistant, thiab tiv thaiv- laus, haum rau lub tshuab nqus tsev daim ntaub ntawv thiab cov twj paj nruag.
● Lub teeb yuag, cov lus teb ceev ceev, lub neej ntev, txhawb kev hloov kho nrog kev sib koom ua ke NTC thermistor kub ntsuas qhov chaw.
Qhov tsis zoo & ceev faj
* Tsis tuaj yeem txiav rau qhov loj me! Internally, nws nta ib tug etched hlau Circuit Court; txiav nws yuav ua rau luv luv thiab hlawv tawm. Qhov loj me yuav tsum yog kev cai- ua ntawm lub Hoobkas.
* Tsis txhob quab yuam khoov, ntswj, lossis khawb cov xim daj PI insulating zaj duab xis, vim qhov no yuav ua rau tawg thiab tawg.
* Cov qauv nplaum- cov qauv thim rov qab tsis tuaj yeem muab tso rau hauv dej; dej yuav nkag rau hauv cov npoo. Waterproofing yuav tsum tau kev cai -ua ntug sealing ntawm lub Hoobkas.
* Nws yuav tsum nyob ze nrog cov khoom raug cua sov; qhuav cua sov thaum tshem tawm tau yooj yim ua rau overheating thiab burnout. Nws raug nquahu kom siv lub tshuab ntsuas kub / ntsuas kub; tsis txhob ncaj qha muab tag nrho lub zog rau ncua sij hawm yam tsis muaj lub cuab yeej.
* Cov nplaum nplaum muaj qhov kub tsis kam: PSA siab zoo tib yam - cov nplaum nplaum muaj qhov tsis kam ntawm kwv yees li 100-120℃. Rau cov ntawv thov kub kub, xaiv cov silicone nplaum txheej version.
Tej kev siv
◎ Cua sov ntawm 24V qis- cov khoom siv hluav taws xob, roj teeb pob preheating, thiab rwb thaiv tsev ntawm lub zog cia cell.
◎ Cov kws tshuaj ntsuam xyuas, cov cuab yeej zoo nkauj, tiv thaiv -condensation ntawm optical lo ntsiab muag, thiab me me rhuab txaj modules rau 3D tshuab luam ntawv.
◎ Sab nraum zoov tswj kev lag luam, qis- kub preheating ntawm LCD zaub, sensor kub tswj, thiab preheating ntawm me me pwm.
