Lub hauv paus ntsiab lus, cov yam ntxwv, thiab tsis muaj kub dabtsi yog khoov electromechanical cua sov kav

1: Lub hauv paus ntsiab lus ntawm kub dabtsi yog khoov electromechanical cua sov raj:
Qhov kub dabtsi yog khoov electromechanical cua sov raj yog tsim thiab tsim raws li qhov kub thiab txias ntawm cov neeg siv khoom. Raws li cov neeg siv khoom xav tau siv lub taub hau hluav taws xob cua sov lub raj nyob rau hauv qhov kub thiab txias, lub raj kub kub ntawm ib lub taub hau hluav taws xob cua sov raj yuav muaj qhov tshwm sim yaj. Yog li ntawd, siv cov hlaws dai ceramic es tsis txhob siv cov raj kub kub tuaj yeem tiv thaiv melting thiab ua rau kom muaj kev pab cuam lub neej. Shenzhen Xinhongda Hluav taws xob cua sov Technology Co., Ltd., raws li ntau tshaj 20 xyoo ntawm kev paub thiab technology nyob rau hauv tsim ib lub taub hau cua sov rods, tsom rau kev tshawb fawb thiab kev loj hlob ntawm high-zoo thiab high-end high-temperature resistant ib lub taub hau hluav taws xob cua sov. rods rau kub dabtsi yog khoov tshuab pwm, thiab muab kub uniformity technology daws rau kub dabtsi yog khoov tshuab.
Lub raj cua sov no yog tshwj xeeb rau kev kho kom haum rau 3D iav kub dabtsi yog khoov tshuab, featuring kub tsis kam, tsis zoo cua sov, segmented cua sov, thiab ntev kev pab cuam lub neej. Qhov kub sib txawv ntawm ob qhov ntsuas kub ntsuas ntawm cov pwm yog qhov me me, thiab lub raj cua sov tuaj yeem ua haujlwm ntawm qhov kub ntawm ib ncig ntawm 950 degree, nrog rau qhov kub sib txawv ntawm tsawg dua 15 degree rau tag nrho cov pwm.
2: Parameters ntawm ib lub taub hau hluav taws xob cua sov yeeb nkab rau kub dabtsi yog khoov tshuab:
Rated voltage: 380V
Rated zog: 900W
Cua sov yeeb nkab txoj kab uas hla: 20mm
Cua sov raj ntev: 220mm ± 1mm
Cua sov cheeb tsam ntev: 195mm
3: Cov khoom xaiv ntawm ib lub taub hau hluav taws xob cua sov raj rau kub dabtsi yog khoov tshuab:
Cov khoom siv cua sov: incoloy800 nickel alloy seamless steel yeeb nkab
Nickel chromium los yog nickel manganese multi-strand txhuas hlau: kub tsis kam siab tshaj 1280 degree
Cov khoom siv hluav taws xob cua sov: nickel chromium hlau: (NiCr8020) (kub tsis kam tshaj 1200 degree)
Insulation material: Magnesium oxide powder with high temperature resistance not less than 1600 ℃ (purity>97%)
Magnesium oxide pas nrig nrog kub tsis kam tsis tsawg tshaj 1600 degree (purity<99.2%)
4: Kev tsim cov kev cai rau ib lub taub hau hluav taws xob cua sov kav ntawm kub dabtsi yog khoov tshuab:
Lub raj cua sov tuaj yeem ua haujlwm ntawm qhov kub ntawm ib puag ncig 950 degree, nrog qhov kub sib txawv ntawm li 15 degree rau tag nrho cov pwm.
