Yuav ua li cas los tsim ib qho Ultra-Thin Heating Phaj rau qhov chaw-Kev txwv tsis pub siv

Qee cov khoom siv, xws li tes- tuav cov cuab yeej kho mob, cov khoom siv hluav taws xob nqa tau yooj yim, lossis cov cuab yeej ntsuas me me, tsuas yog yuav tsum muaj qhov cua sov ntawm ob peb millimeters tuab. Hefty qub style tuab platens nrog drilled cartridge rhaub. Ultra-thin designs siv lub tshuab cua sov sib txawv.

ULTRA THIN HEATING PLATES
Rau qhov chaw- txwv tsis pub siv, ultra- phaj cua sov yog feem ntau ua los ntawm nyias nyias phaj (1-2mm) lossis mica substrate. Cov ntaub ntawv no tsim lub hauv paus, lub hauv paus txheej txheem ntawm cov khoom cua sov. Nyob rau sab nraum qab ntawm lub substrate yog bonded ib tug etched ntawv ci cua sov caij zoo ib yam li nyob rau hauv tsim rau ib tug saj zawg zog luam Circuit Court. Tag nrho cov sib dhos yog tsim los kom tsawg dua 3 hli nyob rau hauv tag nrho thickness.

Lub etched ntawv ci keeb yog qauv tsim kom muaj cua sov kom raug hla ib qho chaw tiaj tus. Lub tshuab hluav taws xob hluav taws xob tau raug kos los ua kom muaj kev sib koom ua ke tam sim no rau kev tswj cov cua sov. Cov qauv tsim nyias ua kom ua kom muaj zog thiab rov ua haujlwm ntawm tag nrho cov cua sov saum npoo nrog qhov tsawg kawg nkaus thickness.

Ultra-Thin Heating Plate Muaj peev xwm
Cov no ultra- cov cua sov nyias nyias muaj ntau qhov zoo rau qhov chaw- txwv tsis pub siv:

Tsawg mus rau nruab nrab watt densities Cov cua kub no tuaj yeem tsim cov watt tsawg mus rau nruab nrab vim lawv cov kev tsim kho nyias, uas ua rau lawv muaj txiaj ntsig zoo rau cov ntawv thov uas tsis tas yuav tsum muaj siab - kub lossis siab - lub zog cua sov.

Thermal uniformity: etched foil qauv tuaj yeem tsim los muab cov cua sov sib txawv thoob plaws hauv tag nrho saum npoo, ua rau lawv zoo heev rau cov ntawv thov uas xav tau cov cua kub zoo.

Cov lus teb ceev ceev: Ultra- cov cua sov nyias nyias muaj cov cua kub tsis tshua muaj cua sov thiab yog li cuam tshuam sai rau kev hloov pauv ntawm lub zog hluav taws xob. Qhov no tej zaum yuav muaj txiaj ntsig zoo rau cov ntawv thov uas xav tau cov cua kub ceev.

Compact thiab Lub Teeb Nyhav: Lub slim profile ntawm cov phiaj no yog qhov loj ntxiv hauv cov khoom siv me me uas qhov chaw thiab qhov hnyav yog nyob ntawm tus nqi.

Txawm li cas los xij, ultra- cov phaj cua sov nyias tsis siv tau rau hauv cov xwm txheej uas cov khoom siv hnyav hnyav tau kwv yees vim tias lawv tsis muaj kev ncaj ncees los tiv thaiv kev kub ntxhov lossis kev ntxhov siab.

Teeb meem Technical
Kev txwv kub: Etched foil heater technology feem ntau txwv rau kev ua haujlwm kub ntawm 200 degree. Qhov no feem ntau yog vim qhov txwv ntawm cov khoom siv nplaum thiab rwb thaiv tsev hauv kev tsim. Kev kub siab dua yuav tsum tau saib cov txheej txheem sib txawv lossis cov khoom siv.

Thermal uniformity: Cov qauv ntawv ci tuaj yeem raug kho, uas yog qhov zoo tshaj plaws rau cov neeg tsim qauv los txhim kho cov cua kub profile rau ib tus neeg thov kev thov. Qhov no tso cai rau cua sov sib npaug, uas yog qhov tseem ceeb hauv ntau cov khoom siv me me.

Cua sov yees sib piv
Feature|Cartridge Heater PlatensUltra Nyias Etched Foil Heating Phaj
Thickness Feem ntau ntau tshaj 10mmUnder 3mm
Watt Density High, rau kev lag luam cua sovLow- Nruab nrab
Thermal Response Slower vim nce thermal mass Tsawg thermal ceev ceev
Mechanical Load Designed for high -load situationsNot recommend for heavy mechanical loads.
Txwv cov qauv tswj CustomisationCompletely customizable foil designs
Qhov kub thiab txias ~ 200℃saum toj ~ 500℃possibilities
Xaus:
Ultra- cov cua sov nyias nyias muaj txoj hauv kev tshiab los ua kom sov hauv cov ntawv thov uas qhov chaw thiab qhov hnyav nyob ntawm tus nqi. Cov phiajcim no yog ua raws li cov thev naus laus zis ntawm etched ntawv ci ntawm nyias aluminium lossis mica substrates, thiab muab cov cua sov zoo thiab cov khoom siv hluav taws xob me me. Lawv tau txwv qhov kub thiab txias thiab cov khoom siv thauj khoom muaj peev xwm tab sis lawv lub sij hawm teb ceev ceev thiab cov cua kub sib txawv ua rau lawv zoo heev rau kev siv hluav taws xob tsawg tsawg. Nrog rau kev txhim kho sai ntawm cov cuab yeej cua sov, cov kev daws teeb meem cua sov xws li ultra- cov phaj cua sov nyias yuav dhau los ua ib qho tseem ceeb hauv kev ua kom txaus siab qhov xav tau ntawm qhov chaw- txwv cov tshuab.
